| Type | Project description | |
| Electrical specifications | Capacity (depending on model) | 20kvar/30kvar/50kvar/75kvar/100kvar/150kvar |
| Input line voltage | 380V(-40°c~+20°c) | |
| Scope of compensation | Capacitive sensibility is continuously adjustable | |
| Full response time | <=7.8ms | |
| efficiency | Up to 98% | |
| Dry contact | EPO/DI/DO | |
| Communication interface | Communication protocol | RS232/RS485/Ethernet/GPRS |
| Environmental requirements | Operating temperature | -35°c~+55°c |
| structure | Module weight | 20KG~46KG |
| Cooling method | Intelligent air cooling | |
Stationary Generator SVG are mainly used for reactive power compensation, improve power factor, and optimize power quality. HSVG series SVG covers 20kvar, 30kvar, 50kvar, 75kvar, 100kvar, 150kvar and other specifications, with continuously adjustable compensation output, which perfectly solves the shortcomings of traditional reactive power compensator step compensation.
