CBB60 A.C Metallized Film Capacitor

The feature is small in dimension, high capacitance,low  dissipation factor and self-healing character.The capacitors are applied to the motors for washing machine etc.which demand 50/60 Hz A.C power supply.

1.Technical Index

Type	CBB60
Climate category	40/70/21
Rated voltage	250VAC~500VAC
Capacitance range	4uF~40uF
Test voltage VAC	T-T:4.5Un        T-C：》2000VAC 2s.60s        2.0Un
Insulation resistance	T-T:≥3000m ΩμF       T-C:≥1000MΩ
Dissipation factor	Tanδ≤0.002(50/60Hz)         Tanδ≤0.005(50/60Hz)             MPP                                          MPET

 Excuting standards: GB3667 UL810
 Capacity tolerance:±5%,±10%  or fulfilled at the request of customers.
