CBB66S-A Lighting Capacitor

Home > Products > CBB series household capacitor

1.Uses
The product is used in discharge lamp ciruits operating at 50/60hz and altitudes up not than 2000m,It could start illuminate smoothy and improve power effeciency electricity network.

2.Technical Index

Type	CBB66S-A
Climatic category	40/85/21 40/105/21
Capacitance range	4uF~60uF
Test voltage VAC	T-T:2Un 60s T-C:≥25000vac 60s
Insulation resistance	T-T:≤3000s T-C:≥1000MΩ
Rated voltage	250VAC~660VAC
Dissipation factor	Tanδ≤0.002(50HZ/60HZ)

Excuting standards:GB18489-2001 IEC61048-1999
Capacitance tolerance：±5% or according to customer's request
Discharge performance:less than 50V after breakage in 60S at √2 Un
Excepitional specification can be produced on consulation
