CBB81 High-voltage Capacitor
CBB81 high -voltage capacitor is made of metallized polypropylene fim inside structure by eposy resin.They are widely used in electronic instrument and equipment,TV set ,energy saving lamp and other electronic rectifiers,and other high-frequency high-voltage circuits,aso used in AC circuit and DC circuit.
Features
1.Low loss
2.Good self-healing ability
3.Good reliability
4.Wide capacitance range
5.Excellent temperature performance
6.Good high-frequency loss
7.High insulation resistance
8.Withstanding intensity circuits impact
Technical Index:
|
Type |
CBB81 |
|
Capacitance range |
0.001uF~0.015uF |
|
Capacitance tolerance |
J(±5%) K(±10%) |
|
Rated voltage |
1000VDC;1400VDC;1600VDC;2000VDC |
|
Withstand voltage |
2Un,2S |
|
Dissipation factor |
Tanδ≤0.0020(10kHz) |
|
Insulation resistance |
≥10000MΩ (20℃,100V,1MIN) |
|
Climate catagory |
10/105/21 |
